Esame Neural and Machine Learning

"MPG",

"Cylinders",

"Displacement",

"Horsepower",

"Weight",

"Acceleration",

"Model Year",

"Origin",

]

data = pd.read_csv(

url, names=column_names, na_values="?", comment="\t", sep=" ",

skipinitialspace=True

)

data

Check is there are missing entries in the dataset.

print(data.isna().sum())

Remove records with missing entries.

data = data.dropna()

print(data.isna().sum())

## Data inspection

Display some basic information.

data.head()

data.info()

data.describe()

We are interested in predicting the eld `MPG`, measuring [fuel ef ciency](https://

en.wikipedia.org/wiki/

Fuel_ef ciency#:~:text=Fuel%20economy%20is%20the%20distance,a%20certain%

20volume%20of%20fuel)), expressed in miles per gallon (MPG), where 1 MPG =

0.354006 km/L. Plot its distribution.

sns.displot(data["MPG"], kde=True)

Look for linear correlations among data.

data.corr()

sns.heatmap(data.corr(), annot=True, cmap="vlag_r", vmin=-1, vmax=1)

sns.pairplot(data, diag_kind="kde")

## Data normalization

Apply an af ne transformation to the data, so that each feature has zero mean and

unitary standard deviation.

data_mean = data.mean()

data_std = data.std()

data_normalized = (data - data_mean) / data_std

_, ax = plt.subplots(figsize=(16, 6))

sns.violinplot(data=data_normalized, ax=ax)

fi fi fi fi

## Train-validation split

Shuf e the data using the [np.random.shuf e](https://numpy.org/doc/stable/

reference/random/generated/numpy.random.shuf e.html) function and split the data

as follows:

- put 80% in the train dataset

- put 20% in the validation dataset

data_normalized_np = data_normalized.to_numpy()

np.random.seed(0)

np.random.shuffle(data_normalized_np)

fraction_validation = 0.2

num_train = int(data_normalized_np.shape[0] * (1 - fraction_validation))

x_train = data_normalized_np[:num_train, 1:]

y_train = data_normalized_np[:num_train, :1]

x_valid = data_normalized_np[num_train:, 1:]

y_valid = data_normalized_np[num_train:, :1]

print("train set size : %d" % x_train.shape[0])

print("validation set size: %d" % x_valid.shape[0])

## ANN setup

Write a function `params = initialize_params(layers_size)` that initializes the

parameters, given the ANN architecture.

Initialize biases with zero values, and weights with a [Glorot Normal](http://

proceedings.mlr.press/v9/glorot10a/glorot10a.pdf) initialization, i.e. sampling from a

Gaussian distribution with zero mean and with standard deviation

$$

\sqrt{\frac{2}{n + m}},

$$

where $n$ and $m$ are the number of input and output neurons of the

corresponding weights matrix.

def initialize_params(layers_size):

np.random.seed(0) # for reproducibility

params = list()

for i in range(len(layers_size) - 1):

W = np.random.randn(layers_size[i + 1], layers_size[i]) * np.sqrt(

2 / (layers_size[i + 1] + layers_size[i])

)

b = np.zeros((layers_size[i + 1], 1))

params.append(W)

params.append(b)

return params

Implement a generic feedforward ANN with a function `y = ANN(x, params)`, using

$ReLU$ as activation function.

fl fl fl

activation = jax.nn.relu

def ANN(x, params):

layer = x.T

num_layers = int(len(params) / 2 + 1)

weights = params[0::2]

biases = params[1::2]

for i in range(num_layers - 1):

layer = weights[i] @ layer - biases[i]

if i < num_layers - 2:

layer = activation(layer)

return layer.T

params = initialize_params([7, 10, 1])

ANN(x_train[:10, :], params)

Implement the quadratic loss (MSE) function `L = MSE(x, y, params)`.

def MSE(x, y, params):

error = ANN(x, params) - y

return jnp.mean(error * error)

params = initialize_params([7, 10, 1])

print(MSE(x_train, y_train, params))

Implement an $l^2$ regularization term for the ANN weights:

$$

\mathrm{MSW} = \frac{1}{n_{weights}} \sum_{i=1}^{n_{weights}} w_i^2

$$

and define the loss function as

$$

\mathcal{L} = \mathrm{MSE} + \beta \, \mathrm{MSW}

$$

where $\beta$ is a suitable penalization parameter.

def MSW(params):

weights = params[::2]

partial_sum = 0.0

n_weights = 0

for W in weights:

partial_sum += jnp.sum(W * W)

n_weights += W.shape[0] * W.shape[1]

return partial_sum / n_weights

def loss(x, y, params, penalization):

return MSE(x, y, params) + penalization * MSW(params)

print(MSW(params))

print(loss(x_train, y_train, params, 1.0))

Run this cell: we will this callback to monitor training.

from IPython import display

class Callback:

def __init__(self, refresh_rate=250):

self.refresh_rate = refresh_rate

self.fig, self.axs = plt.subplots(1, figsize=(16, 8))

self.epoch = 0

self.__call__(-1)

def __call__(self, epoch):

self.epoch = epoch

if (epoch + 1) % self.refresh_rate == 0:

self.draw()

display.clear_output(wait=True)

display.display(plt.gcf())

time.sleep(1e-16)

def draw(self):

if self.epoch > 0:

self.axs.clear()

self.axs.loglog(history_loss_train, "b-", label="loss train")

self.axs.loglog(history_loss_valid, "r-", label="loss validation")

self.axs.loglog(history_MSE_train, "b--", label="RMSE train")

self.axs.loglog(history_MSE_valid, "r--", label="RMSE validation")

self.axs.legend()

self.axs.set_title("epoch %d" % (self.epoch + 1))

## Training

Train an ANN with two hidden layers with 20 neurons each, using 5000 epochs of

the SGD method (with minibatch size 100) with momentum ($\alpha = 0.9$).

Employ a linear decay of the learning rate:

$$

\lambda_k = \max\left(\lambda_{\textnormal{min}}, \lambda_{\textnormal{max}} \left(1

- \frac{k}{K}\right)\right)

$$

with $\lambda_{\textnormal{min}} = 5e-3$, $\lambda_{\textnormal{max}} = 1e-1$ and

decay length $K= 1000$.

During training, store both the MSE error and the loss function obtained on the train

and validation sets in 4 lists, respectively called:

- `history_loss_train`

- `history_loss_valid`

- `history_MSE_train`

- `history_MSE_valid`

Test different choices of the penalization parameter $\beta$.

# Hyperparameters

layers_size = [7, 20, 20, 1]

penalization = 2.0

# Training options

num_epochs = 5000

learning_rate_max = 1e-1

learning_rate_min = 5e-3

learning_rate_decay = 1000

batch_size = 100

alpha = 0.9

########################################

params = initialize_params(layers_size)

grad = jax.grad(loss, argnums=2)

MSE_jit = jax.jit(MSE)

loss_jit = jax.jit(loss)

grad_jit = jax.jit(grad)

n_samples = x_train.shape[0]

history_loss_train = list()

history_loss_valid = list()

history_MSE_train = list()

history_MSE_valid = list()

def dump():

history_loss_train.append(loss_jit(x_train, y_train, params, penalization))

history_loss_valid.append(loss_jit(x_valid, y_valid, params, penalization))

history_MSE_train.append(MSE_jit(x_train, y_train, params))

history_MSE_valid.append(MSE_jit(x_valid, y_valid, params))

dump()

cb = Callback(refresh_rate=500)

velocity = [0.0 for i in range(len(params))]

for epoch in range(num_epochs):

learning_rate = max(

learning_rate_min, learning_rate_max * (1 - epoch / learning_rate_decay)

)

idxs = np.random.choice(n_samples, batch_size)

grads = grad_jit(x_train[idxs, :], y_train[idxs, :], params, penalization)

for i in range(len(params)):

velocity[i] = alpha * velocity[i] - learning_rate * grads[i]

params[i] += velocity[i]

dump()

cb(epoch)

cb.draw()

print("loss (train ): %1.3e" % history_loss_train[-1])

print("loss (validation): %1.3e" % history_loss_valid[-1])

print("MSE (train ): %1.3e" % history_MSE_train[-1])

print("MSE (validation): %1.3e" % history_MSE_valid[-1])

We now want to to investigate more in depth the effect of the penalization parameter

$\beta$.

Write a function that, given the penalization parameter, trains the ANN (with the

same setting used above) and returns a dictionary containing the nal values of:

- train MSE

- validation MSE

- MSW

# Hyperparameters

layers_size = [7, 20, 20, 1]

# Training options

num_epochs = 5000

learning_rate_max = 1e-1

learning_rate_min = 5e-3

learning_rate_decay = 1000

batch_size = 100

alpha = 0.9

def train(penalization):

params = initialize_params(layers_size)

n_samples = x_train.shape[0]

velocity = [0.0 for i in range(len(params))]

for epoch in range(num_epochs):

learning_rate = max(

learning_rate_min, learning_rate_max * (1 - epoch / learning_rate_decay)

)

idxs = np.random.choice(n_samples, batch_size)

grads = grad_jit(x_train[idxs, :], y_train[idxs, :], params, penalization)

for i in range(len(params)): fi

velocity[i] = alpha * velocity[i] - learning_rate * grads[i]

params[i] += velocity[i]

return {

"MSE_train": MSE(x_train, y_train, params),

"MSE_valid": MSE(x_valid, y_valid, params),

"MSW": MSW(params),

}

Using the above de ned function, store the obtained results for $\beta = 0, 0.25, 0.5,

0.75, \dots, 2$.

results = {

"MSE_train": list(),

"MSE_valid": list(),

"MSW": list(),

}

pen_values = np.arange(0, 2.1, 0.5)

for p in pen_values:

print("training for p = %f..." % p)

res = train(p)

results["MSE_train"].append(res["MSE_train"])

results["MSE_valid"].append(res["MSE_valid"])

results["MSW"].append(res["MSW"])

Plot the trend of the five quantities as functions of $\beta$.

_, axs = plt.subplots(1, 3, figsize=(12, 6))

axs[0].plot(pen_values, results["MSE_train"], "o-")

axs[1].plot(pen_values, results["MSE_valid"], "o-")

axs[2].plot(pen_values, results["MSW"], "o-")

axs[0].set_title("MSE_train")

axs[1].set_title("MSE_valid")

axs[2].set_title("MSW")

Plot the _Tikhonov L-curve_, which is - in this context - the curve "train MSE" versus

"MSW".

plt.plot(results["MSW"], results["MSE_train"], "o-")

plt.xlabel("MSW")

plt.ylabel("MSE_train")

# 1st order Training (optimization) methods

import numpy as np

import matplotlib.pyplot as plt

import time

import jax.numpy as jnp

import jax

Let us consider the following function

fi

$$

f(x) = e^{-\frac{x}{10}}\sin(x) + \frac{1}{10} \cos(\pi x)

$$

defined over the interval $[0, 10]$.

f = lambda x: np.sin(x) * np.exp(-0.1 * x) + 0.1 * np.cos(np.pi * x)

a, b = 0, 10

De ne a function `get_training_data` that returns a collection of `N` training sam
